Anycubic Photon Mono X2 4K High Precision Large Print Size 4K+ Resin LightTurbo LCD 3D Printer Dual Z-axis Linear Rail


SKU: N/A Category:

⭐ Installation Guide:

Technical Specifications

● Z Axis: Double liners with 10um accuracy

● Build Platform: Laser engraved aluminum alloy

● Contrast Ratio: 350:1

● Light Transmittance: 5%

● Exposure Screen: 9.1″monochrome, 4K+(4096x2560px)

● Light Source: < 27,320 lux power density

● Control Panel: 3.5″TFT touch-control

● Power Supply: 100W rated power

● Data Input: USB Type-A 2.0

● Machine Leveling: 4-point manual leveling

● Printing Speed: ≤ 6cm or 2.36in / hr.

● Printing Volume: 4.8L / 162oz

● Printing Dimensions: 7.8*7.7*5in. / 200*196*122 mm (HWD)

● Machine Dimensions: 16.4*11.4*10.2in. / 417*290*260 mm (HWD)

● Machine Weight: 7kg / 15.6lb

*Anycubic Cloud service is not supported for Anycubic Photon Mono X2.

Higher Precision

It has 4K+ screen pixels with a resolution of 4,096 by 2,560px. Up to 48μm single-pixel accuracy, a 4% improvement over Photon Mono X, giving you a higher level of detail.

Creativity Without Limits

With a 9.1’’ monochrome screen, the Anycubic Photon Mono X2 has a 3.8% larger print area than the Photon Mono X. You can print large objects or several miniatures at once. Unleash your imagination and creativity.

Efficient Light Source

Equipped with an improved Anycubic LighTurbo matrix light source that projects UV light both parallel and perpendicular to the LCD screen, providing a more uniform light exposure that improves the quality of printed models.

For Stable Printing

Photon Mono X2 adopts dual linear guides and a POM clearance nut combined with a vibration-absorbing structure to ensure the running accuracy of the z-axis, allowing users to eliminate effectively layer lines.

Laser Engraved Build Plate

The build plate of Anycubic Photon Mono X2 features a textured checkerboard pattern that easier to remove your printed arts and dramatically improves adhesion and print success rate.

Protect What Matters

It comes with a screen protector to prevent you from accidentally scratching and damaging the screen, extending the life of the LCD screen. Also includes1 protection film and tools.
